Stainless Steel Vertical Multistage Centrifugal Pump 50Hz
Stainless Steel Vertical Multistage Centrifugal Pump 50Hz
Stainless Steel Vertical Multistage Centrifugal Pump 50Hz
Stainless Steel Vertical Multistage Centrifugal Pump 50Hz
Model
SDK

Item specifics

The liquid temperature
-15ºCto +70ºC
hot water type
+70ºC to +115ºC
Flow range
0.4m3/h~330m3/h
Head range
Max.366m
The environment temperature
+40ºC

Review

Description

Product features:Stainless Steel Vertical Multistage Centrifugal Pump 50Hz
1. Hot and cold clean, non flammable and explosive, containing no solid particles or fibers of the liquid, .
2. The liquid temperature: -15ºCto +70ºC hot water type -15ºC to +105ºC.
3. Flow range 0.4m3/h~28m3/h, head range 6m~232m.
4. Model range SDK1,2,3,4,8, 12,16,20
5. Material CI, SS304, SS316L, Duplex all available.
6. The environment temperature: +40ºC.
7. The minimum entrance pressure curve: NPSH +0.5m.
8. Head of safety margin of 0.5m.
Data sheet: 50Hz

Model

AS1

AS2

AS3

AS4

rated flow. m3/h

1

2

3

4

Max.head. m

214

232

218

211

Model

AS8

AS12

AS16

AS20

rated flow. m3/h

8

12

16

20

Max.head. m

208

217

222

234

Applications:
